ASUS RS720-E11-RS12U-16W10G Dual Xeon 2U Server
ASUS RS720-E11-RS12U-16W10G Dual Xeon 2U Server
-
Give our server experts a call today to configure this!
Processor / System Bus: Intel®Xeon® Processor Scalable Family
-
Generation: 4th/5th
-
Core Logic: Intel® C741 Chipset
-
Memory:
Total slot:
32 (8-channel per CPU, 16 DIMM per CPU)
Capacity:
Maximum up to 4TB
Memory type:
4th: 4800 MHz (1DPC)/ 4400 MHz (2DPC)
5th: 5600/4800 MHz (1DPC)/4400(2DPC)
Memory size:
64GB, 32GB, 16GB RDIMM
256GB, 128GB RDIMM 3DS
* Refer to www.asus.com/support for more information -
Expansion Slots:
Up to 9 slots
6 x PCIe G5 x8 link or 3 x PCIe G5 x16 link (FHFL or FHHL)
1 x PCIe G5 x16 link (FHHL)
1 x OCP 3.0/PCIe Gen5 x16 link (FHHL)
1 x PCIe G5 x16, LP -
Storage:
12 x 3.5”/2.5" hot-swap bay
8 x NVMe/SAS*/SATA + 4 NVMe/SATA
Optional 2 x 2.5" Rear
Hot-swap Storage Bays (Up to 2x NVMe/SATA)
(*HBA/RAID card is required to support SAS hard drives) -
Drive Bays:
12 x 3.5”/2.5" hot-swap bay
2 x M.2 slot -
System Fan: 4
-
Networking:
4 x1Gbe(Intel I350-AM4) RJ45 port or
2 x 10Gbe(Intel X710-AT2) RJ45 port -
Graphic: Aspeed AST2600 64MB
-
Front I/O Ports: 2 x USB 3.2 Gen1 ports
-
Rear I/O Ports:
2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Management LAN port
2 x 10G or 4 x 1G RJ-45 GbE LAN port (optional) -
Switch/LED:
Front Switch/LED:
1 x Power Switch (w/ LED)
1 x Location Switch (w/ LED) -
Dimensions: 840mm x 447mm x 88mm
-
Form Factor: 2U
-
Weight: 26.855kg
-
Power Supply: 1+1 Redundant AC: 2600W/1600W 80 PLUS Titanium/ Platinum Power Supply
-
CPU Heatsink/ Cooler: Standard/ EVAC Heatsink
